ERV Rubber Expansion Joints
Picture 3
Camlock hose couplings: system comparison
right hand side - industry standard, with cable tighteners to fix levers. Left hand side: Easyloc from Elaflex with automatically secured levers.
ZVA 25
HIFLO-Automatic nozzle DN 25 (1"), flowrate up to 140 litres/min.
Elaflon Plus PTFE 38
Filling of small containers for chemicals
Rubber Expansion Joint ERV-BR 80.16
BR Expansion Joints, special type for abrasive media such as sludges, slurries, solid / liquid mixtures and emulsions, dustlike or powdery products (e. g. carbon-blacks). Also suitable for all kinds of water (non oil containing) as well as various chemicals. Not suitable for petroleum based products. For extreme strain (e.g. sharp and rough-edged matter) we suggest the use of ERV with inner protection sleeve type SR
Pharma hose fittings
AMX ammonia hose
rail tanker Loading/Unloading
ZVA Slimline 2
RS 2 x 3 SS
Reducer Female/Male
SX 50 SS
Spannfix clamp DN 50 of stainless steel
AVKI 38 SSE
Camlock male adapter. Material: stainless steel with universally resistant PFA coating (red)
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Machining spouts
AdBlue® urea solution, road tanker:
DDC-M 50 Dry Disconnect Coupling, UTL 50 hose assembly on reel
ZVF 50 UL for aircraft refuelling with ER 494
EA 909 green, EK 946 green
ZVA Slimline 2 / ZVA Slimline 2 GR
Petrol station nozzles with (top) and without vapour recovery (below)
Alternative fuels: DME Dimethyl Ester
DGC Dry Gas Coupling, EFL 16 Fluorline hose assembly
DDC-V 80 F
Dry Disconnect Coupling for Epoxi resin loading - with sensor
Nozzles and hose assemblies for the forecourt
ZVA Slimline 2, ZVA Slimline 2 GR, Slimline hose assemblies
Ship bunkering with LNG
Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling
AN 2 St
Welding nipple steel
ZVA-GBZ
Automatic nozzle ZVA DN 19, of cast bronze (GBZ), for drinking alcohol, brandy etc. Flowrate up to 60 l / min.
ELAFLEX refuelling equipment:
Quality is in the detail.
ZVG 2 EURO
(Push-In-Coupling) to EN 13760. One-handed operation possible.
EA 866 scuffguard orange with ZVG 2 ACME nozzle
The scuffguard for LPG / Autogas nozzles shows the LPG fuel grade marking required by standard, and offers a large advertising space
Construction site / on site refuelling:
ZVA 32 (automatic nozzle), road tanker
ELAPHARM Type EPH-OHM G
electrically conductive 'OHM/T', with light grey cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, black PTFE liner. Clamp fittings, lining flared (free of dead spaces).
MK 50 SSE
TW female coupler. Material: stainless steel with universally resistant PFA coating (red)
ERV-G Yellow Band rubber expansion joints, pumping system for oil emulsion
ZVF 50 JET overwing refuelling
with HD-C hose assembly
CBC-PERC 100
Cryogenic Breakaway Coupling "PERC" for LNG after pneumatic separation
