VB 100 SSE
TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
ElaSil ELS 38 with DIN 11851 hose fitting, FREE OF DEAD SPACES
Ship bunkering with STW hose assembly and MannTek DDC Dry Disconnect Couplings
Scandinavia
From Terminal To Nozzle
Elaflex refuelling equipment
VKC 75 SS
TW male hose coupling, stainless steel, one part, with Spannfix clamps, with protecting "K"-Ring
ContiTech Production ERV
Vulcanisation
ZVA Slimline 2 nozzles, ESB 16 Safety Breaks, Slimline hose assemblies
Paraguay
Oasis BV708, 1" ball valves, isolation valves, CNG spheres (tanks)
Oasis SV Sandwich Valves 100series, for CNG
Hose Beads
BD 50, BD 63
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose
Manufacturing of stainless steel turned parts
ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid
and Slimline dispensing hose, yellow
ZVA Slimline 2
with Sight Glass
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling ZVA components
ERV-OR
"Orange Band" Rubber Expansion Joints, road tanker
ZVA Slimline 2 GR - spout with vapour suction inlet
Mobile tank for solvents
hose assembly UTS 50 with MKX 50 SS and VB 50 SS
ELAPHARM and SD Pyropal steam hose
Pharmaceutical production
VB 80 Al
TW dust plug, aluminium
ERV Rubber Expansion Joints
Picture 2
ELAFLEX Hamburg
Assembling Spannloc hose clamps
ZVA Slimline 2 DSA, Prepay Dispenser
DSA: Pressure Controlled Safety Shut-Off
ZVF 50 UL91 overwing refuelling
UL 91: new unleaded aviation fuel - identification colour green
AdBlue® urea solution, road tanker:
DDC-M 50 Dry Disconnect Coupling, UTL 50 hose assembly on reel
DAC-V 65
MannTek Dry Aviation Coupling
Elaflon PTFE 50
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Sand casting
ELAPHARM Type EPH 25
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
SPANNFIX pinned safety clamps of aluminium
SX 50 Al
