Dispenser picture to distinguish the three different kinds of Safety Breaks
Hose Break, Pump Break, Nozzle Break
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Sand casting
SPANNLOC bolted safety clamps of stainless steel
SC 75 SS
SC 50 SS
Spannloc clamps, stainless steel
ELAFLEX Hamburg
Assembling Spannfix hose clamps
V 16-1" cr
Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, blue.
Ship bunkering
FHD hose assemblies
ERV-W 80.16 ZS 2
White Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
ERV-G 400.10
DN 400
Construction site / on site refuelling:
ZVA 500 manual bulk nozzle, HD hose assembly, road tanker
Elaflex Pacific (Australia)
Manufacturing GasGuard GG1 nozzle
Oasis SV Sandwich Valves 100series, for CNG
Oasis company building
Lightweight Gravity Discharge Road Tanker Hose LG 3"
with VX 75-3" Al LG
Oasis FV103 45° Fill Valve with NC 203 P36 Nozzle, for CNG
Nozzle boot NB-ZVF 50
for ZVF 50 Oberflügel-Zapfventile
Anti-Kinking Spirals 'KSS' and 'KSS-SD'
The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the Anti-Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Production Picture 18
IBC loading and unloading
MannTek DDC-M 50, FWS 50 PTFE
Hose assembly with STKC 75
Storz coupling with Spannloc clamps
ELAFLEX Hamburg
Assembling ERV large DN
DDC-M 80 SS; SG 3", VC 75-3, Elaflon FEP 75, DDC-K 3" SS ADR
Epoxy resin loading with Dry Disconnect Coupling, sight glass and FEP universal hose. DDC cap with pressure relief at container tank outlet.
Easy Rotating Safety Swivel Break, Type 'ERS'
SSB 16 ERS
SBC-C 150.16
MannTek Safety Breakaway Coupling with cable release, PN 16 flange connection
FFC 50.16 SS
Fixed flange hose fitting of stainless steel, with Spannloc clamps
Airfield fixinstallation: Hose Reels JET, AVGAS
Type HD-C, aviation hose, ZVA 32
LNG Refuelling
LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly
Motorcycle refuelling at the petrol station
ZVA Slimline 2 GR, Germany
Oasis NC 203 P30_P36 Nozzle Couplers
Flexible bronze pipe connectors
Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps
