Media Library / Images

Hose Reels group picture

Movable, pneumatic rewind system, active Vapour Recovery (VR) for gasoline fuels

Elaflon Plus FEP

hose assemblies, lacquer filling

Hose Trolley HTR-T

for terminal operations

Solvapal 32

Solvent hose to EN 12115 for most solvents, paints (also waterbased), water laquer, petroleum products, alcohols, alede hydes, esters and ketones. In short term operation also suitable for aromatic und chlorinated hydrocarbons.

Type PCS 50 (Polypal Clean DN 50 mm)

LPG 16 dispensing hoses for L.P. Gas (Autogas)

black or orange

SMX 50-2"

Female hose coupling of steel with Spannfix clamps

Camlock cam locking couplings

top left – ELAFLEX standard version; bottom right – ELAFLEX EASYLOC version

Elaflon Plus FEP

Embossed hose marking

Hose Reel Spring Rewind, ZVA Slimline 2 blue

Check Valve 350 bar

for Hydrogen

Oasis CNG refuelling equipment:

Ultra Fast Fill System (Diagram, English)

ZVA LV for AdBlue® with EA 075 LV

Urea solution (DEF, ARLA 32) for Light Vehicles

SG 1 1x0 SS for Nozzles for AdBlue®

Attach on dispenser side of swivel

ELAPAC FD flat sealing material

2 or 3 mm thickness, available as coil, standard size seal or in custom shape. An elastic flange seal for tank truck and tank plant construction etc., where rough sealing surfaces require a high adaptability, where flange seals should still have good flexibility to avoid pipe fractures or simple sealing materials because little or no force can be used to tighten the joint.

ERV-OR ... ZS

"Orange Band" Rubber Expansion Joints with limiters; heating plant

Slimline 21 hose assembly with non reattacheable female coupling M 21-1" NR

Universal hose assembly for vehicles fighting dangerous goods incidents:

PTFE 50, length 5 mtr., assembled with MKX 50 SS/Vi SS, VKX 50 SS/Vi SS

TGN 4" Al tank truck flange with threaded nipple, VK 100 Ms male TW coupler, MB 100 Al dust cap, chain

RS 21/2 x3 SS

Reducer Female/Male

Safety Swivel Break

SSB 25

SPANNFIX pinned safety clamps of aluminium

SX 50 NR Al

Hose Reel spring rewind black, FEP 50, DDC-M 50 SS

Chemical manifold

Slimline 21 green

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

Ship bunkering

HD hose assembly on dispenser vehicle

Storz Safety Coupling SHK

upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.

SPANNFIX pinned Sicherheits Klemmbacken aus stainless steel

SX 75 SS

MK "TW" female couplers of stainless steel

special types with bent lever

Rubber Expansion Joint ERV-GS HNBR 80.16

YELLOW STEEL HNBR expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Very good aging, weathering and ozone resistance. Temperature range (depending on medium) - 35° C up to + 100° C, temporarily up to + 120° C. Fire resistant to ISO 15540 up 30 min. at + 800° C. Electrically dissipative.

Elaflex LTW hose assembly, Matterhorn

Supply of the mountain top station via IBC unloading
