ZVG 2 ACME nozzle for L.P. Gas / Autogas, LPG 16 hose assembly, ARK 19 Safety Break
Lube oil plant: manifold with DDC-V Dry Disconnect Couplings
ZVG 2 ACME nozzle for L.P. Gas / Autogas
LPG nozzle for vehicle refuelling with liquefied petroleum gas (propane, butane and mixtures) up to 50 l / min. Working pressure 25 bar. Test pressure 40 bar. Burst pressure > 100 bar. Temperature range - 25° up to + 70° C, 'LT'-Type down to - 40° C.
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
Oasis BV708, 1" ball valves, isolation valves, CNG trailer loading
Manufacturing of turned parts
Rubber Expansion Joint ERV-OR 80.25
ORANGE BAND expansion joints for Liquid Petroleum Gas (LPG) to EN 589. For tank trucks and refuelling stations. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically dissipative.
Storz Safety Coupling SHK
upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.
Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion
Picture courtesy of Macoil International, Gibraltar
Drum unloading; UTS 32 hose assembly
SSB 25 Safety Break: Abriss
ELAFLEX Hamburg
Incoming goods / flanges
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling ZVA components
Maintenance at the petrol station
coupled PTFE hose assemblies, MK 50 SS, Adapter VK 50 SS x VK 50 SS, Spannloc stainless steel clamps
Elaflex hose assemblies, nozzles and Rubber Expansion Joints for the chemical industry
SSB 16 Safety Break: Abriss
Double Closing Safety Swivel Break
SSB 25 DC
Adapters / couplers for vehicles fighting dangerous goods incidents:
Adapters Foodstuff Couplings to DIN 11851 Female Rd 78 x 1/6 SS x VK 50 SS/Vi, Male Rd 78 x 1/6 SS/Vi x MK 50 SS/Vi
Mobile tank for solvents
hose assembly UTS 50 with MKX 50 SS and VB 50 SS
V 16-3/4" NPT
Male ferrule hose coupling EN 14424, reusable. Slimline 19 hose, black.
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
ERV-G 150.TW, ERV-G 80.TW
Aircraft refueller
Marine bunkering and cargo hoses
ship to shore cargo transfer
ERV-G ... TW
"Yellow Band" Rubber Expansion Joints; tank truck
Elaflon Plus FEP 25
Urea solution filling of a car:
ZVA LV for AdBlue®, Slimline 16 for AdBlue® (blue cover)
IBC metal container; UTS hose assembly
LG 2" hose assembly for gravity discharge, respectively for vapour balance
DDC-M 65-2 1/2" Al
MannTek Dry Disconnect Coupling, aluminium
